Efficient Steel Frame Software
The ENDUROCADD® steel frame software is the key feature of the ENDUROFRAME® building system. It's used to detail and engineer light gauge steel house frames for manufacture using the ENDURO® rollformer.
The ability to design and build a wide variety of steel frame buildings starts with the software used to model all the parts digitally.
The ENDUROCADD® software system is the only light gauge steel framing design and detailing software package to be entirely self-certified in accordance with the ABCB Protocol for Structural Software.
Key Benefits
Integrated System
The ENDUROCADD® software has been designed around the ENDURO® rollformer and the ENDUROFRAME® Building System to ensure they work together as a whole. Engineering calculations are carried out within a single program with no need to export to another program.
Self Certification
Jobs that fall within self-certification requirements defined by the ABCB Protocol for Structural Software do not need signing off by an engineer. This can save time and money.
Complies with Applicable Australian Standards
The ENDUROCADD® steel frame software is independently audited for compliance with applicable Australian standards.

Automated Rules
User-defined automated rules ensure that trusses, wall panels and floor joists are built quickly and accurately, saving detailer time compared to manually inserting each time.

Design Manuals
Extensive design manuals complement the ENDUROCADD® steel frame software ensuring a complete design not only covering ENDUROFRAME® sections.

Detailed Costing
Detailed cost reports can be generated including ENDUROFRAME® components, accessories, and fabrication labour based on user inputs.

Tried & Tested
The ENDUROCADD® steel frame software system has been used extensively in steel framing manufacturing plants across the world for over 20 years. This means the system has been rigorously tested and proven to perform.
User Friendly
The ENDUROCADD® software system is a simple yet powerful solution that allows users without specialist CAD skills to quickly detail trusses and wall frames using one program. This can save time and money by allowing you to get started quickly then get the job done without jumping between multiple programs.

BIM Compatible
Walls can be automatically imported into the ENDUROCADD® software and BIM output files can be generated to check against other building elements.

Training
Training available via online videos and tutorials, webinars, and classes organised by experienced Enduroframe staff.

Expanding Detailer Network
There is an expanding network of independent detailers using the ENDUROCADD® software to provide detailing services. There are also many opportunities for detailers who want to provide detailing services.

Cost Effective
ENDUROCADD® software is a cost-effective way to get started detailing light gauge steel frames with licences costing $495 including GST. Steel frame designs with the ENDUROCADD® software can also be a cost effective solution!
Powerful Steel Frame Software for Multiple Building Types
The ENDUROCADD® steel frame software is used in a wide range of building applications providing detailing and engineering capabilities. The gallery below shows 3D models of multiple building types.
- Single Storey
- Multi Storey
- Commercial
Examples of single storey jobs modelled in the ENDUROCADD® software by both Enduroframe and our customers
Single storey jobs are often quite large and can have complex roof shapes. This means that large span trusses are required which can have truss shapes which can vary. All of which is easily possible in the ENDUROCADD® software!
Click on these links to see how these have been modelled using the ENDUROCADD® software.

Single Storey - Fortitude Frames
Job modelled by Fortitude Frames, Tocumwal.
Examples of 2 storey jobs modelled in the ENDUROCADD® software
2 storey jobs have their own unique design challenges. Structural beams and posts are often required however these can be easily modelled in the ENDUROCADD® software to fit in with joists and walls. Pockets can also easily be created to nest beams into.
In addition, floor joists need to align with studs underneath and be braced. The ENDUROFRAME® system makes this easy using our patented integrated flooring system which fixes joists directly to the side of studs.
These models show the variety of 2 storey jobs that our customers use the ENDUROCADD® software for.

2 Storey - Mermaid Waters
Designed by Ultimate Steel Frames, Gold Coast.
Commercial jobs modelled in the ENDUROCADD® software
Commercial building applications are one of the fastest growing markets for light gauge steel frames, but they are often complex buildings requiring sophisticated design solutions, and extensive engineering. Commercial building applications include multi-storey apartments, child care facilities, schools, aged care facilities, fast food stores, and hospitals, to name a few.
The large spanning capacities of the ENDUROFRAME® system mean that often the structural steel quantities can be replaced using ENDUROFRAME® sections, reducing cost and providing a competitive advantage. Below are features in the ENDUROCADD software to make
- Large spanning trusses
- User applied loads
- Voids created in truss webs to allow for ducts
- Integration of structural steel into frames
- Able to break job down into multiple deliveries
- Extensive engineering
- Large bracing loads
- Gutters built into roof trusses
- Able to export into BIM files
Click on the links below to see jobs detailed by ENDUROCADD® software licensees.

Commercial - Fast Food
Designed by Steer Manufacturing, Melbourne, Victoria.

Commercial - School
Designed by Ultimate Steel Frames, Gold Coast, Queensland

Commercial - Aged Care
Designed by Ultimate Steel Frames, Gold Coast, Queensland

Commercial - Child Care
Designed by Ultimate Steel Frames, Gold Coast, Queensland.
Easy to use modelling tools for complex building shapes
The building applications that light gauge steel frames are being used in are getting more and more complicated. Ensure you are using a software package that enables you to model – and therefore build – complex buildings.
The ENDUROCADD® software makes this possible with sophisticated modelling tools.
ENDUROCADD® Software Output Sheets
Outputs from the ENDUROCADD® software are comprehensive, yet clear and simple to read, making approvals, assembly and installation straight forward.
A Solid Design Foundation based on Extensive Testing



There are 2 ways capacities for light gauge steel frames can be generated: calculations and testing.
A defining feature of the ENDUROCADD® software is that much of the design calculations are based on hundreds of tests carried out over decades at BlueScope Steel’s NATA accredited laboratory. Tests are carried out on entire trusses, wall panels, and even connections made from the ENDURO® rollformer using TRUECORE® steel.
Generally, testing provides much better capacities than those developed using calculations while providing certainty that frames will perform the same when constructed as they have been designed.
Better capacities mean less steel needs to be used, saving money. This is one reason we see up to 40% less steel being used than many alternative systems.
Comprehensive Library of Construction Details

Light gauge steel frames are much more than just the sections made on a rollformer. There are many connections and brackets required to connect the frame together…..and these need to be engineered!
Developing a full library of details of connections that are approved by an engineer is both time consuming and expensive. Supplying a building without these is potentially dangerous and risky.
The ENDUROFRAME®️ system makes this easy with a comprehensive range of construction details available out-of-the-box prepared by our light gauge steel experts. These are provided as part of the ENDUROCADD®️ software package.
ENDUROCADD® Software Design Support
Designing cost-effective frames is much more than just designing studs and trusses, and guessing the types and sizes of all ancilliary items. The ENDUROCADD® software makes designing frames simple with extensive design manuals. ENDUROFRAME® components can also be used to design building features using the online Spanman calculator. The design manuals include design information for the following.
- Roof truss and rafter tiedown brackets
- Roof common rafters
- Roof hip rafters
- Verandah rafters
- Roof beams
- Ceiling Joists
- Outriggers including tiedown brackets
- Gable ladders including tiedown brackets
- Jamb studs
- Studs under girder trusses
- Opening headers including trussed heads, beam heads and angle lintels
- Top plate capacities including boxed options
- Stud to plate capacities
- Wall frame tiedowns
- Header and sill lateral restraints
- Floor joist to beam brackets
- Single ENDUROFRAME® sections used as floor joists
- Beams around Stair Voids
- Wind Beams around Stair Voids
- Tiedowns between upper and lower levels
ENDUROCADD® Features
- Input Files
- Output Files
- Code Compliance
- Productivity Tools
- Items Counted
The following input files can be imported into the ENDUROCADD® software to speed up detailing times:-
- DXF
- IFC (walls and openings)
- Excel (used for detailing schedules)
The following input files can be exported from ENDUROCADD® software:-
- DXF
- IFC
- Excel for costing reports
- WRL
- Sketchfab
- XML
The ENDUROCADD® complies with the ABCB Protocol for Structural Software 2011.2 which describes the essential elements of structural software that can be used for designing in compliance with the NCC Deemed-to-Satisfy (DTS) Provisions as well as general requirements for software documentation, testing, quality assurance and user training.
Calculations carried out in the ENDUROCADD® software comply with the following standards:-
- NASH Standard - Residential and Low Rise Steel Framing: Part 1 Design Criteria
- AS/NZS 4600:2018 Cold-Formed Structures
- AS/NZS 1170.0:2002 Structural Design Actions Part 0 - General Principles
- AS/NZS 1170.1:2002 Structural Design Actions Part 1 - Permanent, Imposed and Other Actions
- AS/NZS 1170.2:2021 Structural Design Actions - Wind Actions
- AS 4055:2021 Wind Loads for Housing
- AS 4100:1998 Steel Structures
- BCA 2022 Building Code of Australia
- Single package for detailing and design
- Trace from DXF or PDF
- Import wall IFC file to automatically build walls
- 3D View including via user-defined viewbox
- View selected level(s)
- View numeric control data of any truss, wall or joist
- Quick export 3D model to Sketchfab
- One click to Sketchfab reference tool
- Smart online help system
- Truss shape automatically built based on roof & ceiling planes
- Easy adjust truss web spacing
- Truss connections automatically upgraded based on applied loads
- Truss chords or webs automatically upgraded based on applied loads
- Multiple options to select truss construction method
- Truss costs can be be seen as trusses are edited
- Holes punched in truss chords and rafters for auto-alignment
- Trusses can be built around voids such as ducting or beams
- Automated construction of verges as either gable ladders or outriggers
- Openings configurable based on truss span and opening width to optimise header type, number of jamb studs and tiedown type
- Auto-update walls depending on truss span including boxing top plate, aligning stud under truss, truss-wall tiedown, wall tiedown, and wall anchor bolt
- Studs align to floor joists
- Joists built with user-defined stepdown
- Automatically raise walls to roof plane(s) for gable/skillion wall creation
The ENDUROCADD® software does comprehensive take-offs for accurate costing and easy supply including:-
- All components made on the ENDURO® rollformer
- All fasteners used for fabrication
- All brackets used for fabrication
- Structural steel
- Strap, K, or Sheet Bracing
- Truss and Wall frame tiedowns
- Girder brackets
- Anchor bolts
- Roof battens
- Roof & ceiling bracing
In addition, any other item can be automatically calculated using formulas based on job variables.
ENDUROCADD® Latest News
Next Generation of ENDUROCADD® Steel Frame Software Released
The latest version of ENDUROCADD ships with many new technologies included.
Read MoreHow sophisticated testing leads to cost-effective steel trusses
Extensive research in light gauge truss design can lead to the reduction in the amount of steel that is used....
Read MoreLooking To Reduce Your Steel Truss Costs? Here’s How.
Find out the key factors that can drive the difference in the cost of light gauge steel roof trusses.
Read MoreENDUROCADD® Release V11.01.32 Release Highlights
ENDUROCADD® Software Release V11.01.32 comes with many highly sought after features. It comes free to ENDUROCADD® software licensees.
Read MoreENDUROHUB Version 3 is here!
We've just released Version 3 of ENDUROHUB, and it comes with some major behind-the-scenes improvements including two factor authentication and...
Read MoreENDUROHUB® Batching – Divide and Conquer!
As manufacturing businesses grow, the cost savings that could be made by organizing manufacturing efforts grow. Methods that were once...
Read MoreHow to Purchase
ENDUROCADD® software licenses are included with the purchase of an ENDURO® rollformer, however independent designers can purchase a subscription for $594 per annum. Click here to request a license.
